Public Address Audio Systems Alpha T-2S01 2 Channel Mixer Preamplifier (Rack)

Descriptions Features ■ Chime signal 1: Selective four tone chime (internal setting) 2: Automatic priority 3: Permissible external chime remote and P.T.T. remote 4: Master 1, 2 outputs ■ Two band EQ per outputs ■ Signal indicator per input ■ Independent din jack for P.T.T. remote to work with T-319 ■ Priority switch and phantom of mic2,3,4 ■ Selective MIC input of H.P.F ■ Selective output per input signal (output1,output1+2,output2) ■ Independent line input with RCA pin jack(line7~10) ■ Recording output ■ Led indicator for master-output ■ AC 220V/50Hz, DC 24V Optional ■ Panel with/without handhold ■ Panel black or gold finish Specifications Model T-2S01 Input sensitivity/impedance MIC/ Line -50dBu(2.45mV)/5kΩbal -10cBu(245mV)/5kΩ bal Line rca in -10dBu(245mV)/5kΩunbal Output ievei/impedance Master 1,2 Nor +4dBu/200Ωbal Rec Nor 0dBu/10kΩunbal Frequency response Less Than -0.5dB(20Hz~20KHz) Signal to noise ratio MIC More than 60dB Line More than 75dB T.H.D MIC Less than 0.05% Line More than 0.03% Cross-talk MIC More than 60dB Line More than 75dB Power consumprion power 13W Power(option) ~110V/60Hz, ~220V/240V/50Hz,24V DC(optional) Dimensions ( WxHxD)(mm) 484×44×235 Weight 3.9Kg
